NET TRANSCEIVER SFP+/TL-SM5110-LR TP-LINK
Prekės kodas: @2119929
38,17 €
Užsakomoji prekė.
Numatoma atsiėmimo*/išsiuntimo** data:
2026-03-24*atsiėmimo taške Ozo g. 20, Vilnius
**pristatymas kurjeriu papildomai 1-2 darbo dienos nuo išsiuntimo
- Aprašymas
- Atsiliepimai (0)
Aprašymas
Aprašymas
The TL-SM5110-LR is designed to extend transfer distances based on 10Gbps Ethernet connectivity. It is a 10GBASE-LR high performance 1310 nm single-mode SFP+ transceiver. It supports full duplex, 10G Ethernet connections up to 10 km with 9/125µm fiber cables respectively.
- Single-mode SFP+ LC Transceiver
- Hot-Pluggable with maximum flexibility
- Supports Digital Diagnostic Monitoring (DDM)
- Compatible with 10G Small Form Pluggable Multi-Source Agreement (SFP+ MSA)
- Compatible with switches with 10G SFP+ ports, like JetStream TL-SG3428X, TL-SG3428XMP, and more
Specifikacija
| Summary | TP-Link 10Gbase-LR SFP+ LC Transceiver. SFP transceiver type: Fiber optic, Maximum data transfer rate: 10000 Mbit/s, Interface type: SFP+. Brand compatibility: TP-Link, Compatible products: Switches with 10G SFP+ ports, like JetStream TL-SG3428X, TL-SG3428XMP, and more.. Input voltage: 3.3 V. Certification: FCC, CE. Width: 56.7 mm, Depth: 13.9 mm, Height: 10.3 mm |
| Vendor Homepage | https://www.tp-link.com/uk/service-provider/switch-accessory/tl-sm5110-lr/ |
| Category Code | NTM |
| CnCode | 85176200 |
| Unit Box Height | 0.08 |
| Unit Box Length | 0.125 |
| Unit Box Width | 0.04 |
| Digital Diagnostics Monitoring (DDM) | Yes |
| Duplex system | Full |
| Fiber cable diameters supported (core/cladding) | 9/125 |
| Fiber optic connector | LC |
| Interface type | SFP+ |
| Maximum data transfer rate | 10000 |
| Maximum transfer distance | 10000 |
| Multi-mode fiber (MMF) supported | No |
| Networking standards | IEEE 802.3ae |
| SFP transceiver standard | LR |
| SFP transceiver type | Fiber optic |
| Single-mode fiber (SMF) supported | Yes |
| Wavelength | 1310 |
| Brand compatibility | TP-Link |
| Compatible products | Switches with 10G SFP+ ports, like JetStream TL-SG3428X, TL-SG3428XMP, and more. |
| Hot-Plug support | Yes |
| Hot-swap | Yes |
| Input voltage | 3.3 |
| Certification | FCC, CE |
| Operating relative humidity (H-H) | 10 – 90 |
| Operating temperature (T-T) | 0 – 70 |
| Storage relative humidity (H-H) | 5 – 90 |
| Storage temperature (T-T) | -40 – 85 |
| Depth | 13.9 |
| Height | 10.35 |
| Width | 56.7 |
| Quantity per pack | 1 |
| Package depth | 122.5 |
| Package height | 38.5 |
| Package weight | 60 |
| Package width | 81.5 |
| Harmonized System (HS) code | 85369010 |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.0004 |
| Unit Calculated Weight | 0.063 |
