Jonsbo U4 Pro Midi-Tower, Tempered Glass – baltos spalvos

Aprašymas

• • Elegant Midi Tower in white from Jonsbo
  • Stylish side panel with tempered glass
  • Space for Mini-ITX, Micro-ATX, and ATX motherboards
  • Room for graphics cards up to 330 mm
  • With space for long ATX power supplies up to 190 mm
  • Seven slots for graphics and expansion cards
  • For two 2.5-inch and one 3.5-inch drives

  The features of the Jonsbo U4 Pro Midi Tower in detail

  Externally, the U4 Pro from Jonsbo impresses with its subtle and clear design, the stylish side panel with tempered glass, and the flawless workmanship. The Midi Tower features a power switch on the right side, one USB-C 3.1 and one USB-3.0 port, as well as a combined audio jack. The Midi Tower offers plenty of space for powerful hardware and showcases it beautifully.

  With dimensions of 205 by 426 by 395 millimetres, the U4 Pro from Jonsbo is still quite compact, yet it can accommodate full-sized gaming hardware inside. In addition to a Mini-ITX, Micro-ATX, and ATX motherboard, there is also space for graphics cards up to 330 millimetres in length. With seven slots, there is enough room for expansion cards such as capture cards or sound cards.

  The U4 Pro can accommodate a total of two 2.5-inch and one 3.5-inch drives. For cooling, two 120 mm fans can be mounted at the bottom and one 120 mm fan at the rear. Two additional 120 mm fans can be placed in the top of the elegant case, enhancing the natural chimney effect that benefits the cooling of all components. The power supply is housed at the front of the case and can be up to 190 mm long. There is enough space for CPU coolers with a height of up to 160 mm for common models.

  Specification

  • Dimensions: 205 x 426 x 395 mm (W x H x D)
  • Material: Steel, tempered glass
  • Weight: approx. 6.2 kg
  • Colour: White
  • Motherboard form factor: Mini-ITX, Micro-ATX, ATX
  • Fans (possible):
    2x 120 mm (top)
    1x 120 mm (rear)
    2x 120 mm (bottom)
  • Fans (pre-installed): none
  • Drive bays:
    2x 2.5 inch
    1x 3.5 inch
  • Power supply: ATX (optional)
  • Expansion slots: 4
  • I/O panel:
    1x USB-C 3.1
    1x USB-A 3.0
    1x HD audio
    1x power switch
  • Maximum CPU cooler height: 160 mm
  • Maximum graphics card length: 330 mm
  • Maximum power supply length: 190 mm

  Colour
  Primary Colour	White
  Secondary Colour	Transparent
  Dimensions
  Length / Depth	426 mm
  Width	205 mm
  Height	395 mm
  Weight	6.2 kg
  Case
  Case Type	Mid Tower
  Motherboard Support
  Compatible Motherboard Formats	ATX, Micro-ATX, Mini-ITX
  Max. Motherboard Format	ATX
  Internal Dimensions
  Max. CPU Cooler Height	160 mm
  Max. GPU Length	330 mm
  Max. PSU Length / Depth	190 mm
  Display
  Display Included	No
  Power Supply
  PSU included	No
  PSU Format	ATX
  Power Supply Position	Internal
  Fan Support
  120 mm fans	5
  Radiator Support
  Max. Radiator Compatibility	no
  Drive Bays
  2.5 inch internal drive bay	2
  3.5 inch internal drive bay	1
  Hot swap drive bays	No
  External Ports
  USB 3.1 (external) Type C	1
  USB 3.0 (external) Type A	1
  Audio outputs & inputs	1x output / input comb. (3.5 mm jack, 4-pin, TRRS)
  Card reader	No
  Case Features
  I/O position	Front
  Side panel	closed
  Front door	No
  Cable Management	No
  Filters Included	No
  Noise dampening	No
  Mainboard slide / tray	No
  Remote included	No
  Transport System	No
  Features
  Housing Feedthrough	No
  Materials
  Materials	Steel, Tempered Glass
  Lighting
  Lighting / RGB	No
  Fan / RGB control	No
  Additional Contents
  Included fans	None
