GIGABYTE Z890 EAGLE Motherboard, Socket LGA 1851, Intel Z890, ATX, DDR5
Z890 EAGLE
259,70 €
Užsakomoji prekė.
Numatoma atsiėmimo*/išsiuntimo** data:
*atsiėmimo taške Ozo g. 20, Vilnius
**pristatymas kurjeriu papildomai 1-2 darbo dienos nuo išsiuntimo
Pranešti kai prekė vėl bus prekyboje
- Aprašymas
- Atsiliepimai (0)
Aprašymas
ATX-Mainboard with Intel Z890 chipset, 1x PCIe 5.0 x16 / 2x PCIe 4.0 x4, 1x USB4 / 2x USB-C 3.2 / 2x USB 3.1 / 5x USB 3.0 / 8x USB 2.0, 4x M.2 (1x PCIe 5.0, 3x PCIe 4.0) / 4x SATA 6G, 6x 4-pin PWM connectors
This motherboard is ideal for content creators and gamers.
- 1x PCIe 5.0 x16 (x16), 2x PCIe 4.0 x16 (x4)
- 4x DIMM slots for up to 256 GB DDR5 RAM at 8,800 MHz (XMP 3.0 support)
- 4x M.2 (including 1x PCIe 5.0 and 3x PCIe 4.0) / 4x SATA 6G
- USB on I/O panel: 1x USB4, 1x USB Type-C 3.2, 3x USB 3.1, 3x USB 3.0
- OC features: Support for Q-Flash, 14+1+2 power phases
- In total, 6x 4-pin connectors for fans & pumps
GIGABYTE Z890 EAGLE: ATX-Mainboard with Intel LGA 1851 socket and Z890 chipset
The GIGABYTE Z890 EAGLE is an ATX motherboard with the high-end Intel Z890 chipset and the LGA 1851 socket. It supports 2nd generation Intel Core Ultra processors with the Arrow Lake code name. The Intel Z890 motherboard natively supports USB4, offering data transfer speeds of up to 40 Gbit/s. Additionally, the GIGABYTE Z890 EAGLE features full PCIe 5.0 connectivity, providing double the bandwidth for graphics cards and NVMe SSDs compared to PCIe 4.0.
- Form factor:
ATX (305 x 244 mm) - Chipset:
Intel Z890 - Socket:
LGA 1851 (for 2nd generation Intel Core Ultra CPUs) - RAM:
4x DDR5 DIMM (up to 8,800 MHz via XMP)
Dual-Channel
Max. 256 GB - Slots (physical):
1x PCIe 5.0 x16 (electrical x16 or x8/x8)
2x PCIe 4.0 x16 (electrical x4) - Total usable PCIe lanes: 44
- Internal connectors:
4x SATA 6G (max.)
1x M.2 (PCIe 5.0 x4, CPU)
1x M.2 (PCIe 4.0 x4, CPU)
1x M.2 (PCIe 4.0 x4, chipset)
1x M.2 (PCIe 4.0 x4, chipset)
1x USB-C (1 header, USB 3.2 Gen 2, max. 10 Gbit/s)
1x USB 3.0 (1 header, USB 3.2 Gen 1, max. 5 Gbit/s)
2x USB 2.0 (1 header, max. 480 Mbit/s)
1x power button
1x Q-Flash Plus button
1x reset button
1x reset jumper
1x Clear CMOS jumper - Fan headers:
1x 4-pin CPU fan header
1x 4-pin CPU OPT fan header
1x 4-pin AIO pump header
3x case fans (4-pin) - External connectors:
1x USB4 (Type-C, USB4 Gen 2×2, max. 20 Gbit/s)
2x USB 3.1 (Type-A, USB 3.2 Gen 2, max. 10 Gbit/s)
3x USB 3.0 (Type-A, USB 3.2 Gen 1, max. 5 Gbit/s)
4x USB 2.0 (Type-A, max. 480 Mbit/s)
1x DisplayPort
1x 2.5 Gigabit LAN
3x 3.5 mm jack - Power supply:
1x 24-pin ATX
2x 8-pin ATX12V
|
Colour
|
|
|
Primary Colour
|
Black
|
|
Dimensions
|
|
|
Length / Depth
|
305 mm
|
|
Width
|
244 mm
|
|
Form Factor
|
|
|
Motherboard formfactor
|
ATX
|
|
CPU
|
|
|
CPU Manufacturer
|
Intel
|
|
CPU Socket
|
1851
|
|
Motherboard
|
|
|
Motherboard Chipset
|
Intel Z890
|
|
Built-In I/O Shield
|
Yes
|
|
Memory
|
|
|
Max. Memory
|
256 GB
|
|
Memory Type
|
DDR5
|
|
Memory Form Factor
|
DIMM
|
|
Max. Memory Speed (OC)
|
8800 MT/s
|
|
Memory slots
|
4x
|
|
Wi-Fi & LAN
|
|
|
LAN
|
Yes
|
|
LAN Ports
|
1x (in total)
|
|
Wi-Fi / Bluetooth
|
No
|
|
Cooling
|
|
|
Backplate
|
No
|
|
M.2 Heatsinks
|
Yes
|
|
VRM Heatsinks
|
Yes
|
|
Internal Ports
|
|
|
CPU Power Supply
|
2x 8-Pin
|
|
USB 3.0 / 3.1 / 3.2 (internal) Type C Header
|
1
|
|
USB 3.0 (internal) Header
|
1
|
|
USB 2.0 (internal) Header
|
2
|
|
Front Panel Audio Header
|
Yes
|
|
External Ports
|
|
|
USB4 Gen 2×2 (external) Type C
|
1
|
|
USB 3.1 (external) Type A
|
2
|
|
USB 3.0 (external) Type A
|
3
|
|
USB 2.0 (external) Type A
|
4
|
|
Display Connectors
|
Display Port (1x)
|
|
Storage Ports
|
|
|
M.2 PCIe 4.0 x4
|
3
|
|
M.2 PCIe 5.0 x4
|
1
|
|
SATA 6G (internal)
|
4
|
|
Back Connect
|
|
|
Back Connect
|
No
|
|
Expansion Slots
|
|
|
PCIe x16 slots (total)
|
3
|
|
PCIe 5.0 x16 mechanical slot
|
1
|
|
PCIe 4.0 x16 mechanical slot
|
2
|
|
Fan Header
|
|
|
4 Pin Fan Connectors
|
6
|
|
Lighting
|
|
|
Lighting / RGB
|
Yes
|
