GIGABYTE B650E AORUS Stealth ICE, Socket AM5, AMD B650E, ATX – DDR5
B650E A STEALTH ICE
360,31 €
Užsakomoji prekė.
Numatoma atsiėmimo*/išsiuntimo** data:
*atsiėmimo taške Ozo g. 20, Vilnius
**pristatymas kurjeriu papildomai 1-2 darbo dienos nuo išsiuntimo
Pranešti kai prekė vėl bus prekyboje
- Aprašymas
- Atsiliepimai (0)
Aprašymas
ATX motherboard with B650E chipset, AMD AM5 socket, PCIe 5.0 for graphics cards, DDR5 up to 8,000 MHz, 1x M.2-PCIe-5.0 slot, 3x M.2-PCIe-4.0 slots, 4x SATA, 2.5 Gbit LAN / WiFi / Bluetooth 5.4
- 1x PCIe 5.0 x16 (x16)-Slot for your graphics card
- DDR5 memory up to 8,000MHz
- 1x M.2 PCIe 5.0, 3x M.2 PCIe 4.0, and 4x SATA
- USB on I/O Panel: 1x USB-C 3.2 and 11x USB-A
- 2.5-Gbit LAN, WiFi 7, Bluetooth 5.4
- Supports AMD Ryzen 7000 / 8000 / 9000
Designed for ATX Cases and AMD Processors
The B650E AORUS STEALTH ICE by Gigabyte is specifically developed for AMD processors from the 7000, 8000, and 9000 series. Its ATX form factor allows easy installation into a mid-tower case.
You can expand the DDR5 memory up to 256GB across four RAM slots, ensuring your PC handles even the most demanding multitasking tasks effortlessly. Additionally, the memory can be overclocked up to 8,000MHz.
Extensive Connectivity and M.2 SSD Support
This motherboard offers ample connectivity options for your peripherals and hardware. The PCIe 5.0 and 4.0 slots support high-speed M.2 SSDs, eliminating long load times in games. It also includes four SATA ports.
Moreover, the motherboard features a fast 2.5-Gigabit LAN port, supports the latest WiFi 7 standard, and includes Bluetooth 5.4.
Innovative Cooling and Software
The optimized thermal design of the motherboard ensures optimal CPU, chipset, and SSD stability and low temperatures, even under full load. You can easily make various adjustments through the BIOS. The Gigabyte Control Center allows you to customize numerous settings.
For optimal processor performance, it’s recommended to regularly update the BIOS of the motherboard. This is especially important for motherboards that may be shipped with an early BIOS version from the manufacturer.
Our King Mod Service will gladly perform a BIOS update to the latest version in advance:
Please note that this may delay shipping preparation by 1 to 4 working days!
- Format: ATX (305 x 244 mm)
- Chipset: AMD B650E
- Socket: AM5
- RAM:
4x DDR5 (5,200 MHz, up to 8,000 MHz via OC)
Dual-Channel
max. 256 GB - Slots:
1x PCIe 5.0 x16 (electrically x16, CPU) - Internal connections:
4x SATA 6G
1x M.2 (M-Key, PCIe 5.0 x4/x2, 2580 / 2280 / 25110 / 22110, CPU)
2x M.2 (M-Key, PCIe 4.0 x4/x2, 2280 / 22110, CPU)
1x M.2 (M-Key, PCIe 4.0 x4/x2, 2280 / 22110, chipset)
1x USB-C (1 Header, USB 3.2 Gen 2, max. 20 Gbit/s)
2x USB 3.0 (1 Header, USB 3.0, max. 5 Gbit/s)
4x USB 2.0 (2 Header, max. 480 Mbit/s)
1x TPM header
1x Chassis Intrusion
1x Reset Button
1x Start Button
1x Front Panel Header
1x Front Panel Audio Header
1x Clear CMOS jumper
2x Antennas (Wi-Fi 7, Bluetooth 5.4) - RGB Header:
2x ARGB Header (3-Pin, 5 V)
1x RGB Header - Fan Header:
1x CPU Fan (4-Pin)
1x CPU Fan Pump Header (4-Pin)
1x Fan / Pump (4-Pin)
3x Case Fans (4-Pin) - External connections:
1x USB-C (USB 3.2, max. 10 Gbit/s with DisplayPort)
2x USB-A (USB 3.1, max. 10 Gbit/s)
5x USB-A (USB 3.0, max. 5 Gbit/s)
4x USB-A (USB 2.0, max. 480 Mbit/s)
1x HDMI 1.4
1x 2.5-Gigabit LAN
3x 3.5 mm jack - Power supply:
1x 24-Pin ATX
1x 8-Pin
|
Colour
|
|
|
Primary Colour
|
White
|
|
Secondary Colour
|
Silver
|
|
Dimensions
|
|
|
Length / Depth
|
305 mm
|
|
Width
|
244 mm
|
|
Form Factor
|
|
|
Motherboard formfactor
|
ATX
|
|
CPU
|
|
|
CPU Manufacturer
|
AMD
|
|
CPU Socket
|
AM5
|
|
Motherboard
|
|
|
Motherboard Chipset
|
AMD B650E
|
|
Dual BIOS
|
No
|
|
Built-In I/O Shield
|
Yes
|
|
Memory
|
|
|
Max. Memory
|
256 GB
|
|
Memory Type
|
DDR5
|
|
Memory Form Factor
|
DIMM
|
|
System Memory Subtype
|
UDIMM
|
|
Max. Memory Speed (Standard)
|
5200 MT/s
|
|
Max. Memory Speed (OC)
|
8000 MT/s
|
|
EEC Support
|
No
|
|
Memory slots
|
4x
|
|
Performance Profile
|
AMD EXPO
|
|
Wi-Fi & LAN
|
|
|
LAN
|
Yes
|
|
LAN Ports
|
1x 2.5 Gbit/s
|
|
Wi-Fi / Bluetooth
|
Yes
|
|
Wi-Fi Standard
|
Wi-Fi 7
|
|
Bluetooth Standard
|
5.4
|
|
Cooling
|
|
|
Backplate
|
Yes
|
|
M.2 Heatsinks
|
Yes
|
|
VRM Heatsinks
|
Yes
|
|
Water Cooling
|
|
|
Watercooling
|
No
|
|
Internal Ports
|
|
|
CPU Power Supply
|
1x 8-Pin
|
|
USB 3.0 / 3.1 / 3.2 (internal) Type C Possible Ports
|
1
|
|
USB 3.0 (internal) Possible Ports
|
2
|
|
USB 2.0 (internal) Possible Ports
|
4
|
|
Front Panel Audio Header
|
Yes
|
|
External Ports
|
|
|
USB 3.2 (external) Type C
|
1
|
|
USB 3.1 (external) Type A
|
2
|
|
USB 3.0 (external) Type A
|
5
|
|
USB 2.0 (external) Type A
|
4
|
|
Display Connectors
|
HDMI (1x)
|
|
Storage Ports
|
|
|
M.2 PCIe 4.0 x4
|
3
|
|
M.2 PCIe 5.0 x4
|
1
|
|
SATA 6G (internal)
|
4
|
|
Back Connect
|
|
|
Back Connect
|
Yes
|
|
Back-Connect Compatibility
|
Gigabyte Project Stealth
|
|
Expansion Slots
|
|
|
PCIe x16 slots (total)
|
1
|
|
Fan Header
|
|
|
4 Pin Fan Connectors
|
6
|
|
Audio
|
|
|
Soundchip
|
Realtek ALC897
|
|
Lighting
|
|
|
Lighting / RGB
|
Yes
|
|
Lighting Compatibility
|
GIGABYTE RGB Fusion
|
