GIGABYTE B650E Aorus Elite X AX ICE, AMD B650E pagrindinė plokštė – Sockel AM5, DDR5
Prekės kodas: 1244598
B650E AORUS ELITE X AX ICE
243,26 €
- Aprašymas
- Atsiliepimai (0)
Aprašymas
- AMD Socket AM5：Supports AMD Ryzen 7000 / Ryzen 8000 / Ryzen 9000 Series Processors
- Digital twin 12+2+2 phases VRM solution
- Dual Channel DDR5：4*DIMMs with AMD EXPO & Intel XMP Memory Module Support
- PCIe UD Slot X： PCIe 5.0 x16 slot with 10X strength for graphics card
- EZ-Latch Click：M.2 heatsinks with screwless design
- EZ-Latch Plus：M.2 slots with Quick Release & Screwless Design
- Sensor Panel Link：Onboard video port for hassle-free in-chassis panel setup
- UC BIOS：User-Centred intuitive UX with Quick Access function
- Ultra-Fast Storage：3*M.2 slots, including 1* PCIe 5.0 x16
- Efficient Overall Thermal：VRM Thermal Armor Advanced & M.2 Thermal Guard XL
- Fast Networking：2.5GbE LAN & Wi-Fi 6E with Ultra-high gain antenna
- Extended Connectivity：HDMI, Rear USB-C support up to 40Gb/s, Front USB-C 20Gb/s
- Reliable Audio：8-Ch HD Audio & Audiophile Grade Capacitors
Elevate your computing experience with GIGABYTE’s renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you’re a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge
Colour | |
Primary Colour | White |
Secondary Colour | Black, Grey |
Form Factor | |
Motherboard formfactor | ATX |
CPU | |
CPU Manufacturer | AMD |
CPU Socket | AM5 |
Motherboard | |
Motherboard Chipset | AMD B650E |
Memory | |
Max. Memory | 192 GB |
Memory Type | DDR5 |
Memory Form Factor | DIMM |
Memory slots | 4x |
Wi-Fi & LAN | |
LAN | Yes |
LAN Ports | 1x 2.5 Gbit/s |
Wi-Fi / Bluetooth | Yes |
Internal Ports | |
CPU Power Supply | 1x 4-Pin + 1x 8-Pin |
USB 3.0 / 3.1 / 3.2 (internal) Type C Possible Ports | 1 |
USB 3.0 (internal) Possible Ports | 2 |
RGB / LED connectors | 1x RGB (4-Pin 5050 12VGRB), 3x Digital RGB (3-Pin 5VDG) |
External Ports | |
USB 3.1 (external) Type C | 1 |
USB 3.1 (external) Type A | 2 |
USB 3.0 (external) Type A | 5 |
Display Connectors | HDMI (1x), USB Type C (Display Port shared) (1x) |
Storage Ports | |
M.2 PCIe 4.0 x4 | 2 |
SATA 6G (internal) | 4 |
Expansion Slots | |
PCIe x16 slots (total) | 3 |
PCIe 5.0 x16 mechanical slot | 1 |
PCIe 3.0 x16 mechanical slot | 2 |
Fan Header | |
4 Pin Fan Connectors | 6 |
Lighting | |
Lighting / RGB | Yes |
Lighting Colour | RGB |
