Digital Clamp Meter Habotest HT208D

Prekės kodas: 473190

49,02

LIKUTIS: Turime
Pristatymo laikas: 3-5 d. d.
2025-03-17
PASITEIRAUTI APIE PREKĘ

    PARAŠYKITE MUMS:

    Aprašymas

    Habotest HT208D digital clamp meter

    HT208D is a practical device with which you can check the value of various parameters, for example, AC and DC voltage and current, resistance, temperature, inrush current and many others. The product provides accurate measurements, and the results are displayed on the LCD screen. The HT208D also features a flashlight for convenient operation in dark rooms.

    Multifunctional device

    You will use the HT208D in many situations. You can check the value of AC voltage, resistance, capacitance, temperature, frequency, NCV, etc. Furthermore, you can also check continuity and true RMS value.

    Safe use

    The device is completely safe to use. You can, for example, detect voltage without touching, thanks to the NCV sensors. The meter’s jaws, thanks to their maximum width of 40 mm, allow you to make measurements comfortably without damaging the circuit. The flashlight function ensures comfortable and safe work in dark rooms.

    Additional features

    When it receives an electromagnetic signal, the NCV sensor will send an audible alarm, and if the voltage or current is high, the LCD screen color will turn orange. What’s more, the device will automatically turn off to save power if no action is performed within 15 min.

    Function HT208A HT208D
    DC voltage

    6V/60V/600V/1000V

    ±(1%+3)

    6V/60V/600V/1000V

    ±(1%+3)

    AC voltage

    6V/60V/600V/750V

    ±(1.2%+3)

    6V/60V/600V/750V

    ±(1.2%+3)

    DC current n/a

    60A/600A/1000A ±(2.5%+5)

    AC current

    60A/600A/1000A

    ±(3.0%+5)

    60A/600A/1000A

    ±(3.0%+5)

    Resistance

    600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ

    ±(1.0%+3)

    600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ

    ±(1.0%+3)

    Capacity

    10nF/100nF/1μF/10μF/100μF/1mF/10mF ±(4.0%+3),

    100mF ±(5.0%+5)



     10nF/100nF/1μF/10μF/100μF/1mF/10mF±(4.0%+3),

    100mF ±(5.0%+5)

    Frequency

     10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz

    ±(1.0%+3)

    10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz

    ±(1.0%+3)

    Duty

     1%~99%

    ±(1.0%+2)

    1%~99%

    ±(1.0%+2)

    Temperature

     -40°C~1000°C

    ±(1.0%+3)

    -40°C~1000°C

    ±(1.0%+3)

    Counts  6000 6000

    Auto/manual range

     Yes Yes
    Continuity  Yes, LED and buzz Yes, LED and buzz
    Diode  Yes Yes
    Data hold  Yes Yes
    NCV  Yes, LED and buzz Yes, LED and buzz
    Double color backlight  Yes Yes
    Flashlight  Yes Yes

    Low battery indicator

     Yes Yes
    Auto power off  Yes Yes
    True RMS  Yes Yes
    LPF  Yes Yes
    MAX/MIN  Yes Yes
    V-LoZ  No Yes
    Power  2x AA batteries (in the box) 2x AA batteries (in the box)
    Weight  about 380 g about 380 g
    Size  240 x 85 x 40 mm 240 x 85 x 40 mm
    Size of jaws  44 mm 44 mm
    Safety

    EN61010-1, -2-030 EN61010-2-033,

    EN61326-1 CAT III 1000V, CATIV 600V

    EN61010-1, -2-030 EN61010-2-033,

    EN61326-1 CAT III 1000V, CATIV 600V
